DSSA 4.00 is a double-sided median barrier tested to EN 1317 for containment level H1, with working width W6 (1.9 m) and posts every 4000 mm. The system belongs to the DDSP — median family and is supplied as a complete kit — W-beams, posts, spacers, bolts and accessories — all hot-dip galvanized.
DSSA 4.00 technical specifications
| Drawing number | S1.1-130 |
|---|---|
| Containment level (EN 1317) | H1 |
| Working width | W6 (1.9 m) |
| Impact severity level (ASI) | A |
| Test length | 60 m |
| Construction height | 750 mm |
| Construction width | 800 mm |
| Distance between posts | 4000 mm |
| Weight (profile A) | 34.6 kg/m |
| Weight (profile B) | 32.7 kg/m |
