EDSP

HSSA 2.00

Name: HSSA 2.00 highway guardrail
Brand: Sepehr Sanat Steela
SKU: S1.1-120

HSSA 2.00 is a higher-containment barrier tested to EN 1317 for containment level H1, with working width W5 (1.6 m) and posts every 2000 mm.

HSSA 2.00 is a higher-containment barrier tested to EN 1317 for containment level H1, with working width W5 (1.6 m) and posts every 2000 mm. The system belongs to the EDSP — higher containment family and is supplied as a complete kit — W-beams, posts, spacers, bolts and accessories — all hot-dip galvanized.

HSSA 2.00 technical specifications

HSSA 2.00 — EN 1317 data
Drawing number	S1.1-120
Containment level (EN 1317)	H1
Working width	W5 (1.6 m)
Impact severity level (ASI)	A
Test length	60 m
Construction height	750 mm
Construction width	500 mm
Distance between posts	2000 mm
Weight (profile A)	25.4 kg/m
Weight (profile B)	24.4 kg/m

Need help choosing the containment level?

Send us the road type, design speed and available working width — our engineers will recommend a tested system and send a quote.
