HSSA-P 1.33

Name: HSSA-P 1.33 highway guardrail
Brand: Sepehr Sanat Steela
SKU: S1.2-120

HSSA-P 1.33 is a higher-containment barrier tested to EN 1317 for containment level H1 / H2, with working width W5 (1.6 m) / W7 (2.2 m) and posts every 1330 mm.

HSSA-P 1.33 is a higher-containment barrier tested to EN 1317 for containment level H1 / H2, with working width W5 (1.6 m) / W7 (2.2 m) and posts every 1330 mm. The system belongs to the EDSP — higher containment family and is supplied as a complete kit — W-beams, posts, spacers, bolts and accessories — all hot-dip galvanized.

HSSA-P 1.33 technical specifications

HSSA-P 1.33 — EN 1317 data
Drawing number	S1.2-120
Containment level (EN 1317)	H1 / H2
Working width	W5 (1.6 m) / W7 (2.2 m)
Impact severity level (ASI)	A / A
Test length	68 m / 80 m
Construction height	650 mm
Construction width	500 mm
Distance between posts	1330 mm
Weight (profile A)	29.1 kg/m
Weight (profile B)	28.1 kg/m

Need help choosing the containment level?

Send us the road type, design speed and available working width — our engineers will recommend a tested system and send a quote.
